Product Details:
|
|
Place of Origin: | China |
---|---|
Brand Name: | Mason |
Certification: | SGS CE |
Model Number: | M-000 |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 45SHEETS |
Price: | Negotiable |
Packaging Details: | Max 1700kgs on one pallet |
Delivery Time: | 7-15DAYS |
Payment Terms: | T/T, Western Union, MoneyGram |
Supply Ability: | 10000KGS PER DAY |
High Gloss Clear Acrylic Sheet Plexiglass 4 X 8 Sheet
Plexiglass
Description
Crystal clear,transparent and colorless,this acrylic sheet is highly versatile and suited for almost any application.
It is a popular alternative to glass due to its lighter weight and greater impact resistance. Like all acrylics, this
sheet can be easily cut, formed and fabricated.
Applications
From aquariums to architecture, boats to bathrooms, fashion to furniture and glazing to gliders and shop signs
to shelving. The list is almost endless. But don’t just take our word for it…
MASON CLEAR CAST ACRYLIC PARAMETER
Item | Test Result | Item | Test Result |
Transmittance% | 93.4 | Tensile Strain at Break, Mpa | 5.3 |
Rockwell Hardness(M) | 97.3 | Modulus of elasticity in tension, Mpa | 3.03 |
Vicat Softening Temperature(1.8MPA) | 101.1 | Rockwell Hardness(R) | 124 |
Coefficient of Thermal Expansion ℃-1 | 7.0*10-5 | Resistance to crazing in solvent | No crazing |
Dimensional Stability(shrinkage) % | 1.9 | Charpy Non-notch Impact Strength KJ/M2 | 21.9(C) |
Tensile strength, Mpa | 74.7 |
MASON ACRYLIC SPECIFICATION
(The specification is 3mm plate, size will decreases with the increase of thickness)
Code | Size with rubber edge | Size after cut edge |
Q | 1250*1850mm | 1210*1820mm |
L0 | 1250*2450mm | 1220*2440mm |
L1 | 1270*2490mm | 1220*2440mm |
L2 | 1310*2530mm | 1270*2490mm |
L3 | 1350*2570mm | 1310*2530mm |
N | 1550*3050mm | 1510*3020mm |
M | 2050*3050mm(Include Frosted) | 2010*3010mm(Include Frosted) |
Product Display
FOCUS ON ACRYLIC ONE STOP SOLUTION
100% VIRGIN PMMA
The raw materials selection of clear acrylic panels is very strict and meticulous. Lucite and Mitsubishi are
our long-term raw material suppliers.
CLEAR ACRYLIC PANELS PRODUCED BY CASTING TECHNOLOGY
PACKING DETAILS
Clear acrylic panels double size with craft paper film or PE film protection.
