Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | Mason |
| Certification: | SGS CE |
| Model Number: | M-000 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 45SHEETS |
| Price: | Negotiable |
| Packaging Details: | Max 1500kgs on one pallet |
| Delivery Time: | 7-15DAYS |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 10000KGS PER DAY |
100% Vigin MMA Material Plastic Acrylic Sheet Pmma
Cast Plexiglass Sheet
Information
Name: Cast Acrylic Sheet
Color: Clear
Grade: Optical
Specifications:1220*2440mm;
1510*3020mm etc.
Parameter
Density: 1.2kg/m3
Thickness: 3-20mm
Transmittance: 93.4%
Raw Material: Lucite MMA
Description
Cast plexiglass is the highest quality plexiglass acrylic and more cheaper than extruded because it offers the
best optical clarity, greater thermal stability, and higher chemical resistance to solvents. Cast plexiglass acrylic
has a less consistent sheet thickness with up to +/-10% variation possible across the panel;it is thermo-formable
and can be reworked hot, which is not always possible with extruded sheets.
Applications
ADVERTISING SIGNAGE, FURNITURE AND DESIGN, VISUAL COMMUNICATION, LIGHTING ETC
MASON CLEAR CAST ACRYLIC PARAMETER
|
Item |
Test Result |
Item |
Test Result |
|
Transmittance% |
94 |
Tensile Strain at Break, Mpa |
5 |
|
Rockwell Hardness(M) |
97 |
Modulus of elasticity in tension, Mpa |
3.03 |
|
Vicat Softening Temperature(1.8MPA) |
101 |
Rockwell Hardness(R) |
124 |
|
Coefficient of Thermal Expansion ℃-1 |
7.0*10-5 |
Resistance to crazing in solvent |
No crazing |
|
Dimensional Stability(shrinkage) % |
1.9 |
Charpy Non-notch Impact Strength KJ/M2 |
21.9(C) |
|
Tensile strength, Mpa |
74.7 |
|
|
MASON ACRYLIC SPECIFICATION
(The specification is 3mm plate, size will decreases with the increase of thickness)
|
Code |
Size with rubber edge |
Size after cut edge |
|
Q |
1250*1850mm |
1210*1820mm |
|
L0 |
1250*2450mm |
1210*2420mm |
|
L1 |
1270*2490mm |
1220*2440mm |
|
L3 |
1350*2570mm |
1310*2530mm |
|
N |
1550*3050mm |
1510*3020mm |
|
M |
2050*3050mm |
2010*3010mm |
Product Display
FOCUS ON ACRYLIC ONE STOP SOLUTION
100% VIRGIN PMMA
Quality is fundamental to our survival, selection of raw materials is the basis of our work and providing
different levels of products according to customer needs is our responsibility.
PRODUCED BY CASTING TECHNOLOGY
MASON acrylic is produced by the famous brand MMA and matching all kinds of latest imported assembly
line production equipment as well as Pilkington glass molds imported from British.
The tolerance control of plates is very strict, and each plate needs to be adjusted and inspected three times
through the gauge.
PACKAGES
FAQS
Do you have other service?
Besides acrylic sheet material, we also do acrylic cut to size, polish and make acrylic products.
What's your advantage?
We have competitive price cause we usually sell with big lot
What type acrylic sheet do you sell?
Our do many type acrylic sheet, like clear acrylic,color acrylic,forested acrylic ,mirror acrylic,ESD acrylic,
sanitary special acrylic and ect. you could mix the type for ur order if u need.
